1. Used for thickness determination of various woven fabrics, knitted fabrics and non-woven fabrics. 2. Basic application Film, sheet, separator suitable for thickness testing of film, sheet and separator 3. Suitable for thickness testing of paper and cardboard 4. Suitable for thickness testing of foil and silicon wafer 5. Thickness test for metal sheet 6. Thickness test for textile materials 7. Thickness test for solid electrical insulators 8. Suitable for thickness testing of non-woven materials, such as thickness testing of diapers and sanitary napkin sheets 9. Extended to 5, 10mm is suitable for testing the thickness of sheets and plates 10. Suitable for thickness testing with special requirements 【Relevant Standards】

GB/T3820；FZ/T60004；FZ/T60003；ISO5084，9073；ASTM D1777 等。

【Scope of application】: 1. Used for thickness determination of various woven fabrics, knitted fabrics and non-woven fabrics. 2. Basic application Film, sheet, separator suitable for thickness testing of film, sheet, separator 3. Suitable for thickness testing of paper and cardboard 4. It is suitable for the thickness test of foil and silicon wafers 5. Suitable for thickness testing of metal sheets 6. Suitable for thickness testing of textile materials 7. Suitable for thickness testing of solid electrical insulators 8. Suitable for thickness testing of non-woven materials, such as thickness testing of diapers and sanitary napkin sheets 9. The range is extended to 5, 10mm is suitable for testing the thickness of sheets and plates 10. Suitable for thickness testing with special requirements [Method standard]:GB/T3820；FZ/T60004；FZ/T60003；ISO5084，9073；ASTM D1777 等。 【Product Features】: 1. The contact measurement method is adopted, which strictly meets the requirements of the standard and effectively ensures the standardization and accuracy of the test. 2. The contact area and measurement pressure are strictly designed in accordance with the standard, and various non-standard customizations are supported 3. The measuring head is automatically raised and lowered during the test, which effectively avoids errors caused by human factors 4. Support two measurement modes, automatic and manual, which is convenient for users to choose independently 5. Real-time display of the maximum, minimum, average value and standard deviation of the measurement results and other analysis data, which is convenient for users to judge 6. Configure standard gauge blocks for system calibration to ensure test accuracy and data consistency 【Technical Parameters】:
